1. හැඳින්වීම
Thank you for choosing the Claiks Electric Standing Desk. This manual provides essential information for the safe and efficient use of your new desk. Please read it thoroughly before assembly and operation, and keep it for future reference.
Electric standing desks are increasingly adopted in modern workplaces for their ergonomic benefits. They allow users to alternate between sitting and standing positions, which can help alleviate discomfort in the back and hips often associated with prolonged sitting, and improve focus and productivity. Experience a healthier and more efficient work style with your Claiks standing desk.
Image: Claiks Electric Standing Desk in a modern office setting, showcasing එහි සිනිඳු නිර්මාණය සහ ක්රියාකාරීත්වය.
2. නිෂ්පාදන ලක්ෂණ
- සකස් කළ හැකි උස: The desk offers a height adjustment range from 72cm to 118cm, with a lifting speed of 20mm/s. This allows for flexible use as a gaming desk, office desk, or study table, adapting to various user needs.
- මතක කාර්යය: Store up to 3 preferred height settings for quick and easy one-touch adjustments between sitting and standing positions.
- High Performance & Load Capacity: Equipped with reinforced steel legs and a high-performance motor, ensuring excellent load-bearing capacity and durability. The maximum load capacity is 80kg, accommodating multiple monitors and gaming equipment.
- Safe and Durable Tabletop: The tabletop is made from environmentally friendly materials with low indoor air pollutant emissions. It features melamine resin, making it resistant to water, heat, and stains, and easy to clean.
- නිහඬ මෙහෙයුම: Designed for extremely quiet operation, allowing you to enjoy a peaceful working environment.
Image: The Claiks Electric Standing Desk illustrating its adjustable height range from 72cm to 118cm.
Image: A person sitting on the Claiks Electric Standing Desk, demonstrating its robust 80kg load capacity.
Image: Visual representation of the Claiks Electric Standing Desk's quiet operation, indicating a noise level of approximately 45dB.
3. සැකසීම සහ එකලස් කිරීම
Before starting assembly, please ensure all parts are present and undamaged. Refer to the parts list below and the assembly videos for detailed instructions.
රූපය: පුපුරා ගිය එකක් view showing all components included with the Claiks Electric Standing Desk for assembly.
එකලස් කිරීමේ වීඩියෝ:
ErGear Electric Standing Desk Assembly Guide
Video: A comprehensive assembly guide for the ErGear Electric Standing Desk, demonstrating step-by-step installation of components.
Anovara Standing Desk Assembly Video
Video: An assembly video for the Anovara Standing Desk, providing visual instructions for putting the desk together.
Dripex Electric Standing Desk Assembly and Usage
Video: This video demonstrates the assembly process and various usage scenarios for the Dripex Electric Standing Desk.
4. මෙහෙයුම් උපදෙස්
The Claiks Electric Standing Desk features an intuitive control panel for easy height adjustment and memory settings.
Image: The multi-functional control panel of the Claiks Electric Standing Desk, featuring an LED display, memory buttons (1, 2, 3), and up/down adjustment buttons.
4.1. උස සකස් කිරීම
- භාවිතා කරන්න ඉහළට (▲) සහ පහළට (▼) මේසය ඔබට අවශ්ය උසට ඔසවා තැබීමට හෝ පහත් කිරීමට පාලක පැනලයේ ඊතල බොත්තම් භාවිතා කරන්න.
- The current height will be displayed on the LED screen.
4.2. Setting Memory Presets
The desk allows you to save up to three preferred height settings:
- ඉහළ/පහළ බොත්තම් භාවිතයෙන් මේසය ඔබට අවශ්ය උසට සකසන්න.
- ඔබන්න M button. The LED display will show "S-".
- Within 3 seconds, press one of the number buttons (1, 2, හෝ 3) to save the current height to that preset. The display will show "S-1", "S-2", or "S-3" to confirm.
4.3. මතක පෙරසිටුවීම් භාවිතා කිරීම
- Simply press the corresponding number button (1, 2, හෝ 3) මේසය සුරකින ලද උසට ස්වයංක්රීයව ගෙනයාමට.
4.4. නැවත පිහිටුවීමේ කාර්යය
- If the desk encounters an issue or needs to be recalibrated, press and hold the පහළට (▼) button until the desk reaches its lowest position and then slightly rises. This performs a full reset.
5. නඩත්තු කිරීම
- පිරිසිදු කිරීම: Wipe the tabletop and frame with a soft, damp cloth. Avoid abrasive cleaners or harsh chemicals that could damage the surface.
- නිතිපතා චෙක්පත්: Periodically check all screws and connections to ensure they are tight. Retighten if necessary to maintain stability.
- කේබල් කළමනාකරණය: Utilize the integrated cable clips and hooks to keep cables tidy and prevent them from interfering with the desk's movement.
6. දෝශ නිරාකරණය
| ගැටලුව | විය හැකි හේතුව | විසඳුම |
|---|---|---|
| මේසය චලනය නොවේ. | Power cable disconnected, overload, or motor error. | Check power connection. Reduce load on the desk. Perform a reset (see 4.4). |
| Uneven height adjustment. | Synchronization issue between legs. | Perform a reset (see 4.4). Ensure all screws are tightened. |
| දෝෂ කේතය දර්ශනය විය. | Specific system error. | Perform a reset (see 4.4). If the error persists, contact customer support. |
7. පිරිවිතර
Image: A diagram illustrating the dimensions of the Claiks Electric Standing Desk, including width, depth, and height range.
| විශේෂාංගය | විස්තර |
|---|---|
| වෙළඳ නාමය | ක්ලේක්ස් |
| ආදර්ශ අංකය | P1.01.001.0009.JP |
| මේස වර්ගය | විදුලි ස්ථාවර මේසය |
| වර්ණය | සුදු |
| මානයන් (ඩී x ඩබ්ලිව් x එච්) | 60cm x 140cm x 70cm (initial height) |
| උස ගැලපුම් පරාසය | 72cm සිට 118cm දක්වා |
| ඉසිලීමේ වේගය | 20mm/s |
| උපරිම බර පැටවීමේ ධාරිතාව | 80kg |
| මූලික ද්රව්ය | කාබන් වානේ |
| ටැබ්ලට් නිමාව | Laminate (Melamine Resin) |
| විශේෂ ලක්ෂණ | Compact, Scratch Resistant, Memory Function |
8. වගකීම් සහ සහාය
Claiks is committed to providing high-quality products and excellent customer service. All Claiks electric standing desks come with a වසර 3ක නිෂ්පාදකයාගේ වගකීමක්.
During the warranty period, we offer free repair or replacement services for any manufacturing defects. Our customer support team is available to assist you in multiple languages, including Japanese and English. Please feel free to contact us anytime for assistance.
