හැඳින්වීම
This manual provides essential information for the safe and efficient operation of your DARAN Portable Power Station. Please read it thoroughly before use and retain it for future reference. This power station is designed to provide reliable power for various applications, including outdoor activities, RV use, and emergency home backup.
1. පිහිටුවීම
1.1 පැකේජයේ අන්තර්ගතය
සියලුම අයිතම පැකේජයේ ඇති බව තහවුරු කරගන්න:
- 1 × NEOS Power Station
- 1 × AC Charging Cable
- 1 × පරිශීලක අත්පොත
1.2 මූලික ආරෝපණය
Before first use, it is recommended to fully charge the power station. The unit supports multiple charging methods:
- AC Wall Outlet: Connect the provided AC charging cable to the power station's AC input port and then to a standard wall outlet. The unit can recharge to 80% in approximately 2 hours.
- සූර්ය පැනලය (විකල්ප): Connect a compatible solar panel (not included) to the DC input port. The power station supports solar input for charging.
- Car Charger (Optional): The unit can be charged via a car charging cable (not included) through the DC input port.
රූපය 1: ඉදිරිපස view of the DARAN Portable Power Station NEO, showing the display and various output ports.
Figure 2: Illustration of the various charging methods for the power station, including AC wall charging, solar charging, and car charging.
2. මෙහෙයුම
2.1 බල ගැන්වීම සක්රිය / අක්රිය කිරීම
To power on the unit, press and hold the main power button. The digital display will illuminate, showing the battery status and output information. To power off, press and hold the main power button again.
ප්රතිදාන වරායන් 2.2 ක්
The DARAN Portable Power Station features multiple output ports to power various devices:
- AC අලෙවිසැල් (x2): Provides 600W continuous power (1200W surge). Suitable for appliances like car refrigerators and CPAP machines.
- USB-C PD60W (x1): For fast charging compatible USB-C devices.
- USB-A (x2): Provides 18W output for charging smartphones, tablets, and other USB-powered devices.
- DC ප්රතිදානය: For devices requiring DC power.
සටහන: Ensure that the total power consumption of connected devices does not exceed 600W to prevent overload.
Figure 3: The power station connected to various devices, demonstrating its multi-port functionality for camping සහ එළිමහන් භාවිතය.
2.3 ඒකාබද්ධ LED ආලෝකය
The power station includes an integrated LED light with multiple modes:
- Normal Illumination: Provides steady light for general use.
- SOS මාදිලිය: හදිසි අවස්ථා සඳහා දැල්වෙන SOS සංඥාවක් සක්රීය කරයි.
To activate the LED light, press the dedicated LED button. Press again to cycle through modes or turn off.
Figure 4: The power station providing illumination via its integrated LED light during an outdoor evening setting.
3. නඩත්තු කිරීම
3.1 බැටරි සත්කාර
The power station uses a LiFePO4 battery, known for its long lifespan and safety. It is designed for 3500+ charge cycles, maintaining approximately 80% of its original capacity after this period.
- For optimal battery health, avoid completely draining the battery frequently.
- සෘජු හිරු එළියෙන් සහ අධික උෂ්ණත්වයන්ගෙන් ඈත්ව සිසිල් වියළි ස්ථානයක ඒකකය ගබඩා කරන්න.
- දිගු කාලයක් ගබඩා කරන්නේ නම්, සෑම මාස 3-6 කට වරක් බැටරිය ආසන්න වශයෙන් 50-80% දක්වා ආරෝපණය කරන්න.
රූපය 5: අභ්යන්තර view illustration highlighting the LiFePO4 battery technology and its long cycle life.
3.2 පිරිසිදු කිරීම
Use a soft, dry cloth to clean the exterior of the power station. Do not use abrasive cleaners or immerse the unit in water.
4. දෝශ නිරාකරණය
4.1 පොදු ගැටළු
- ඒකකය ක්රියාත්මක නොවේ:
Ensure the battery is charged. Connect to an AC outlet for at least 30 minutes to see if it powers on.
- AC Output Not Working:
If the battery level is below 10%, the AC port will automatically turn off to prevent battery damage. DC/USB ports will remain available. Check if the connected device exceeds the 600W output limit.
- මන්දගාමී ආරෝපණය:
Ensure the charging cable is securely connected. If using solar, verify the solar panel is in direct sunlight and correctly oriented. Check the input wattage තිරයේ දිස්වේ.
- අධි බර ආරක්ෂාව:
The unit has built-in overload protection. If an overload occurs, the unit may shut down. Disconnect the overloaded device, wait a few minutes, and then restart the power station.
4.2 සහාය අමතන්න
If you encounter issues not covered in this section, or if troubleshooting steps do not resolve the problem, please contact DARAN customer service for assistance. Refer to the "Warranty & Support" section for contact information.
5. පිරිවිතර
| විශේෂාංගය | විස්තර |
|---|---|
| ආදර්ශ අංකය | NEO |
| ධාරිතාව | 288Wh (90,000mAh, 3.2V) |
| AC ප්රතිදානය | 600W (1200W සර්ජ්) |
| බැටරි වර්ගය | LiFePO4 (ලිතියම් යකඩ පොස්පේට්) |
| සයිකල් ජීවිතය | 80% ධාරිතාව දක්වා චක්ර 3500+ |
| නිෂ්පාදන මානයන් | අඟල් 8 x 3 x 12 |
| අයිතමයේ බර | රාත්තල් 13.77 කි |
| ආරෝපණ කාලය (AC) | Approx. 2 hours to 80% |
| නිෂ්පාදකයා | Dongguan Menche Electronics Co., Ltd. |
| පළමු දිනය තිබේ | 28 ජූලි 2025 |
6. වගකීම් සහ සහාය
6.1 වගකීම් තොරතුරු
For detailed warranty terms and conditions, please refer to the warranty card included with your product or visit the official DARAN website. The warranty typically covers manufacturing defects and malfunctions under normal use.
6.2 පාරිභෝගික සහාය
If you have any questions, require technical assistance, or need to report an issue, please contact DARAN customer service. Contact information can typically be found on the product packaging, the official DARAN webඅඩවිය, හෝ ඇතුළත් ලියකියවිලි තුළ.
When contacting support, please have your product model number (NEO) and purchase date available.
