Nitecore CL10 Multipurpose Clip-on Light User Manual

1. හැඳින්වීම

The Nitecore CL10 is a versatile and ultra-lightweight clip-on light designed for various applications, including outdoor activities, daily tasks, and emergency situations. It features multiple light sources, including white, red, and blue, with different brightness levels and special warning modes. Its compact design and durable construction make it a reliable lighting tool.

රූපය 1.1: ඉවරයිview of the Nitecore CL10 Clip-on Light, highlighting its three light sources, red/blue warning flashing, 45 lumens output, 28g weight, and 2x AAA battery requirement.

2. නිෂ්පාදන ලක්ෂණ

• උපරිම ප්රතිදානය: ලුමෙන්ස් 45 ක්.
• බැටරි අනුකූලතාව: Uses 2 x AAA alkaline batteries (included) and is compatible with Ni-MH batteries.
• ධාවන කාලය: Provides a max runtime of 28 hours.
• ආලෝක ප්රභවයන්: Features 2 brightness levels of white light, 3 light sources (white, red, blue), and 1 special mode (Red/Blue Warning Flashing).
• ඉදිකිරීම්: Made from special PC plastic with high impact and low-temperature resistance.
• නිර්මාණය: පහසුවෙන් ගෙනයාම සඳහා සංයුක්ත සහ සැහැල්ලු.
• කල්පැවැත්ම: බලපෑම මීටර් 1 දක්වා ප්රතිරෝධී වේ.
• ජල ආරක්ෂිත ශ්රේණිගත කිරීම: IPX4, providing protection against splashing water from any direction.

Image 2.1: Visual representation of the CL10's key features, including its output, battery compatibility, durability, and waterproof rating, shown with the light in an outdoor setting.

3. පැකේජ අන්තර්ගතය

කරුණාකර පහත අයිතම සඳහා පැකේජය පරීක්ෂා කරන්න:

• Nitecore CL10 Clip-on Light Unit
• 2 x AAA Eco Sensa Batteries

4. බැටරි ස්ථාපනය

The Nitecore CL10 operates on two AAA batteries. Follow these steps to install them:

1. Locate the battery compartment cover on the back of the CL10 unit.
2. බැටරි මැදිරි කවරය විවෘත කරන්න.
3. Insert two AAA batteries according to the polarity markings (+ and -) inside the compartment. Ensure correct orientation to prevent damage.
4. බැටරි මැදිරි කවරය ආරක්ෂිතව වසා දමන්න.

සටහන: The CL10 is compatible with both alkaline and Ni-MH AAA batteries. Always use batteries of the same type and charge level.

5. මෙහෙයුම් උපදෙස්

The CL10 features a single power button for all operations.

5.1. බලය සක්‍රිය / අක්‍රිය කරන්න

• සක්රිය කිරීමට: Press and hold the power button for approximately 1 second. The light will turn on in the last used mode.
• නිවා දැමීමට: While the light is on, press and hold the power button for approximately 1 second.

5.2. Mode Selection (While On)

Once the light is on, short press the power button to cycle through the available modes:

• White Light High (45 Lumens)
• White Light Low (20 Lumens)
• Red Constant-On (5 Lumens)
• Blue Constant-On (3 Lumens)
• Red/Blue Warning Flashing (5 Lumens)

Image 5.1: The CL10 providing close-range white light illumination, suitable for tasks like document checking or emergency lighting.

Image 5.2: The CL10 displaying its Red Constant-On and Blue Constant-On modes, useful for warning signaling and preserving night vision.

5.3. Adjustable Angle

The CL10 features an approximate 180° adjustable angle. Rotate the light unit to your preferred lighting angle with one hand to prevent it from shining directly into your eyes or others.

Image 5.3: Illustration of the CL10's 180-degree adjustable head, allowing users to direct the light as needed.

5.4. Versatile Clip Usage

The integrated clip allows for firm attachment and hands-free operation. It can be attached to various items such as clothing (chest, shoulder), cap brims, or backpacks. The clip also helps prevent accidental activation during carrying or storage by covering the power button.

රූපය 5.4: උදාamples of how the CL10's versatile clip can be used, showing attachment to a chest pocket, shoulder strap, and cap brim for hands-free lighting.

6. නඩත්තු කිරීම

• පිරිසිදු කිරීම: Wipe the light with a clean, soft cloth. Do not use abrasive cleaners or solvents.
• බැටරි ආදේශනය: Replace batteries when the light dims significantly or fails to turn on. Always dispose of used batteries responsibly.
• ගබඩා: දිගු කාලයක් ආලෝකය ගබඩා කරන්නේ නම්, කාන්දු වීම හා හානි වැළැක්වීම සඳහා බැටරි ඉවත් කරන්න. සිසිල්, වියළි ස්ථානයක ගබඩා කරන්න.

7. පිරිවිතර

The following table details the technical specifications of the Nitecore CL10:

Image 7.1: Detailed technical data table for the Nitecore CL10, including output, runtime, beam distance, and intensity for all light modes.

Note: The stated data is measured using 2 x 1.5V alkaline AAA batteries in accordance with the international flashlight testing standards ANSI/PLATO FL 1-2019 at an ambient temperature of 26°C (79°F) from the NITECORE Lab. The data may vary in real-world use due to different environmental conditions.

Image 7.2: The CL10 shown in hand, emphasizing its compact size and ultra-lightweight design of 28 grams (0.99 oz).

8. දෝශ නිරාකරණය

• ආලෝකය ක්‍රියාත්මක නොවේ:
  • නිසි ධ්‍රැවීයතාවයකින් බැටරි නිවැරදිව ඇතුළු කර ඇත්දැයි පරීක්ෂා කරන්න.
  • බැටරි නැවුම් ඒවා සමඟ ප්රතිස්ථාපනය කරන්න.
  • බැටරි මැදිරි කවරය ආරක්ෂිතව වසා ඇති බවට සහතික වන්න.
• Light Dims or Flickers:
  • බැටරි අඩු විය හැක. ඒවා ප්‍රතිස්ථාපනය කරන්න.
  • බැටරි සම්බන්ධතා පිරිසිදු බව සහතික කර ගන්න.

9. වගකීම් සහ සහාය

The Nitecore CL10 Clip-on Light comes with a manufacturer warranty for මිලදී ගත් දින සිට වසර 2 ක්. For warranty claims or technical support, please contact your authorized Nitecore dealer or visit the official Nitecore webඅඩවිය.
