Yale Standard Digital Safe YSS/250/DB2 User Manual

1. හැඳින්වීම

The Yale Standard Digital Safe YSS/250/DB2 is designed to provide secure storage for your valuables. This safe features a robust solid steel construction, an easy-to-operate digital keypad with an LCD display, and a programmable combination of 3 to 8 digits. For added security, it includes pre-drilled holes for permanent mounting and an incorrect entry alarm system.

Please read this manual carefully before operating your safe to ensure proper use and to maximize its security features.

2. පිහිටුවීම

2.1 ඉවත් කිරීම සහ පරීක්ෂා කිරීම

Carefully remove the safe from its packaging. Inspect the safe for any signs of damage. Ensure all components are present:

• Yale Standard Digital Safe YSS/250/DB2
• 2 Security Override Keys
• Fixing Bolts (for mounting)
• පරිශීලක අත්පොත

2.2 බැටරි ස්ථාපනය

The safe requires 4 AA size (1.5V) batteries for operation. The battery compartment is located inside the door to prevent tampering.

1. Open the safe door using one of the supplied override keys. Insert the key into the keyhole, turn it clockwise, and then turn the handle to open.
2. දොරේ ඇතුළත බැටරි මැදිරි කවරය සොයා ගන්න.
3. කවරය ඉවත් කර නව AA බැටරි 4ක් ඇතුළු කරන්න, නිවැරදි ධ්‍රැවීයතාව (+/-) සහතික කරන්න.
4. බැටරි මැදිරි කවරය ප්රතිස්ථාපනය කරන්න.
5. Test the keypad by entering a default code (if any, refer to specific instructions on the safe itself or packaging) or by setting a new code as described in Section 3.3.

This image displays the Yale Standard Digital Safe YSS/250/DB2 with its door open, showcasing the spacious interior and the electronic keypad on the door. The keypad features a digital display and numeric buttons for code entry.

2.3 සේප්පුව සවි කිරීම

For additional security, the safe can be permanently mounted to a floor, wall, or other hard surface using the pre-drilled holes and supplied fixing bolts.

1. සවි කිරීම සඳහා සුදුසු ස්ථානයක් තෝරන්න, එය ඝන මතුපිටක් බව සහතික කර ගන්න.
2. Open the safe door and locate the pre-drilled holes on the back or bottom of the safe.
3. Mark the drilling points on the chosen surface through the holes in the safe.
4. Move the safe and drill pilot holes into the marked points on the surface.
5. විදින ලද සිදුරු මත ආරක්ෂිත පිටුපස තබන්න.
6. Secure the safe using the supplied fixing bolts, tightening them firmly.

3. මෙහෙයුම් උපදෙස්

3.1 ඩිජිටල් කේතය සමඟ සේප්පුව විවෘත කිරීම

1. Enter your 3 to 8 digit programmable combination on the keypad.
2. Press the 'E' (Enter) button.
3. If the code is correct, the safe will unlock. Turn the handle clockwise within 5 seconds to open the door.

3.2 සේප්පුව වසා දැමීම

Close the safe door and turn the handle counter-clockwise until it is fully engaged. The safe will automatically lock.

3.3 Changing Your Personal Code

It is recommended to change the factory default code immediately after battery installation.

1. With the safe door open, press the red reset button located on the inside of the door, near the hinge.
2. The yellow indicator light on the keypad will illuminate, and the display will show 'PROG'.
3. යතුරු පුවරුවේ ඔබගේ නව ඉලක්කම් 3 සිට 8 දක්වා කේතය ඇතුළත් කරන්න.
4. Press the 'E' (Enter) button to confirm.
5. The display will show 'GOOD' to confirm the new code has been set.
6. With the door still open, test the new code to ensure it works correctly before closing the safe.

3.4 අතින් අභිබවා යාමේ කාර්යය

In case of battery failure or if you forget your digital code, you can open the safe using the security override keys.

1. සාමාන්‍යයෙන් යතුරු පුවරුවේ කුඩා ආවරණයක් පිටුපස සැඟවී ඇති යතුරු සිදුර සොයා ගන්න.
2. Insert one of the supplied override keys into the keyhole.
3. Turn the key clockwise and simultaneously turn the handle to open the safe door.

Important: Store your override keys in a secure location away from the safe. Never store them inside the safe.

3.5 Incorrect Entry Alarm

If an incorrect code is entered 4 consecutive times, an internal alarm will sound for 3 minutes. During this time, the keypad will be locked out, preventing further code entries. The manual override function can still be used during an alarm.

4. නඩත්තු කිරීම

4.1 බැටරි ප්රතිස්ථාපනය

When the batteries are low, the LCD display may show a 'LOW BATT' indicator. Replace all 4 AA batteries as described in Section 2.2 to ensure continuous operation and prevent lockout.

4.2 පිරිසිදු කිරීම

සේප්පුවේ බාහිර කොටස මෘදු, d රෙදි කඩකින් පිරිසිදු කරන්න.amp cloth. Avoid using abrasive cleaners or solvents, as these can damage the finish or keypad.

4.3 යතුරු ගබඩාව

Always keep the security override keys in a safe and accessible location outside of the safe. This ensures you can access the safe if the batteries fail or you forget your code.

5. දෝශ නිරාකරණය

• Safe does not open with digital code:
  – Ensure batteries are not low. Replace if necessary.
  – Re-enter the code carefully. Ensure no buttons are stuck.
  – Use the manual override key to open the safe.
• යතුරු පෑඩය ප්‍රතිචාර නොදක්වයි:
  – Batteries may be completely drained. Replace all 4 AA batteries.
  – If the keypad is locked out due to incorrect entries, wait for the 3-minute alarm period to end or use the override key.
• අනපේක්ෂිත ලෙස අනතුරු ඇඟවීමේ ශබ්දය ඇසෙයි:
  – This indicates 4 consecutive incorrect code entries. Wait for the alarm to stop or use the override key.
• Forgotten digital code:
  – Use the manual override key to open the safe. Once open, you can reset the code as described in Section 3.3.

6. පිරිවිතර

7. වගකීම් සහ සහාය

For warranty information and customer support, please refer to the documentation provided with your purchase or visit the official Yale webවෙබ් අඩවිය. වගකීම් හිමිකම් සඳහා ඔබේ මිලදී ගැනීමේ සාක්ෂි තබා ගන්න.

If you encounter any issues not covered in this manual, please contact Yale customer service for assistance.
