හැඳින්වීම
This manual provides essential information for the safe and efficient operation, maintenance, and troubleshooting of your Einhell TC-PW 610 Compact Pneumatic Impact Wrench. Please read this manual thoroughly before using the tool to ensure proper handling and to maximize its lifespan. This powerful air impact wrench is designed for demanding tasks such as changing tires on vehicles, offering a maximum torque of 610 Nm and a compact design for accessibility.
ආරක්ෂිත උපදෙස්
මෙවලමට තුවාල හා හානි වැළැක්වීම සඳහා පහත සඳහන් ආරක්ෂක පියවරයන් සැමවිටම නිරීක්ෂණය කරන්න:
- ආරක්ෂිත කණ්නාඩි, ශ්රවණ ආරක්ෂණය සහ අත්වැසුම් ඇතුළු සුදුසු පුද්ගලික ආරක්ෂක උපකරණ (PPE) පළඳින්න.
- Ensure the air supply is disconnected before changing accessories or performing maintenance.
- Do not exceed the maximum operating pressure of 8 bar.
- අත් සහ ලිහිල් ඇඳුම් චලනය වන කොටස් වලින් ඈත් කරන්න.
- Use only genuine Einhell accessories or those approved for use with this tool.
- ක්රියාත්මක වන අතරතුර මෙවලම තදින් අල්ලාගෙන සිටින්න.
- මෙවලම වියළි, \u200b\u200bආරක්ෂිත ස්ථානයක, දරුවන්ට ළඟා විය නොහැකි ස්ථානයක ගබඩා කරන්න.
- Regularly inspect the air hose for damage and ensure secure connections.
නිෂ්පාදනය අවසන්view සහ සංරචක
The Einhell TC-PW 610 Compact Pneumatic Impact Wrench comes with several components designed for efficient operation.
Figure 1: The Einhell TC-PW 610 Compact Pneumatic Impact Wrench, including its transport case and various accessories.
ඇතුළත් උපාංග:
- 3 x Impact Wrench Sockets (17mm, 19mm, 21mm)
- 1 x Empty Oil Burette (for lubrication)
- 1 x Connection Fitting (European Shape)
- 1 x Teflon Sealing Strip (10 m)
- 1 x Transport and Storage Case
රූපය 2: සවිස්තරාත්මක view of the included accessories: three color-coded sockets (17mm, 19mm, 21mm), an air connection fitting, Teflon sealing tape, and an oil bottle for maintenance.
රූපය 3: පැති ගැතිfile of the impact wrench, highlighting its compact design and ergonomic handle.
Figure 4: Close-up of the 1/2-inch square drive, where sockets are attached.
සැලසුම
- වායු සැපයුම් සම්බන්ධතාවය: Connect the provided connection fitting to the air inlet of the impact wrench. Use the Teflon sealing strip on the threads to ensure an airtight seal.
- Hose Requirement: For optimal performance, connect the tool to an air compressor using an air hose with a minimum inner diameter of 9mm.
- ලිහිසි තෙල්: Before first use, and regularly thereafter, add a few drops of pneumatic tool oil (not included, use the provided oil burette) into the air inlet. This lubricates the internal components.
- සොකට් ඇමුණුම: Select the appropriate socket (17mm, 19mm, or 21mm) and firmly attach it to the 1/2" square drive.
මෙහෙයුම් උපදෙස්
The Einhell TC-PW 610 is designed for efficient loosening and tightening of fasteners, particularly for vehicle wheel nuts.
Figure 5: Demonstrating the use of the impact wrench for tire changing, highlighting its practical application.
Direction and Torque Control:
The tool features an ergonomic left/right rotation switch and multiple torque settings.
Figure 6: The control switch for selecting rotation direction (left/right) and adjusting torque settings.
- Left Rotation (Loosening): The tool has 1 level for left rotation, providing full power for loosening stubborn fasteners.
- Right Rotation (Tightening): The tool offers 3 levels for right-hand rotation, allowing for controlled tightening. Select the appropriate level based on the required torque for the fastener.
Figure 7: Visual representation of the 4-step torque setting capability, allowing precise control over fastening.
සාමාන්ය මෙහෙයුම:
- Ensure the air compressor is set to the correct pressure (max. 8 bar).
- Select the desired rotation direction and torque setting.
- සොකට් එක ගාංචුව මත තදින් තබන්න.
- Press the trigger to operate the tool. Release the trigger to stop.
- For tightening, always finish with a torque wrench to ensure fasteners are tightened to manufacturer specifications.
Figure 8: The impact wrench is primarily for high-torque applications like tire changing. The image also highlights the importance of a 9mm inner diameter air hose for optimal performance.
නඩත්තු කිරීම
නිතිපතා නඩත්තු කිරීම ඔබේ බලපෑම් යතුරේ ආයු කාලය සහ ප්රශස්ත ක්රියාකාරිත්වය සහතික කරයි.
- ලිහිසි තෙල්: Add 2-3 drops of pneumatic tool oil into the air inlet before and after each use, or at least once daily if used frequently. This prevents corrosion and ensures smooth operation of internal components.
- පිරිසිදු කිරීම: Keep the tool clean and free from dirt and debris. Wipe down the exterior with a damp රෙදි. දරුණු රසායනික ද්රව්ය භාවිතා නොකරන්න.
- වායු පෙරහන: ඔබේ වායු සම්පීඩකයේ අභ්යන්තර වායු පෙරහනක් තිබේ නම්, මෙවලම තුළට දූෂක ද්රව්ය ඇතුළු වීම වැළැක්වීම සඳහා එය නිතිපතා පිරිසිදු කර හෝ ප්රතිස්ථාපනය කර ඇති බවට වග බලා ගන්න.
- ගබඩා: Store the impact wrench and its accessories in the provided transport case in a dry, cool place.
Figure 9: The "OIL" icon serves as a reminder for regular lubrication of the pneumatic tool.
දෝෂගවේෂණය
පොදු ගැටළු සහ ඒවායේ විභව විසඳුම් සඳහා පහත වගුව බලන්න.
| ගැටලුව | විය හැකි හේතුව | විසඳුම |
|---|---|---|
| මෙවලම ක්රියා නොකරයි හෝ අඩු බලයක් ඇත. | Insufficient air pressure; Clogged air inlet; Lack of lubrication; Damaged air hose. | Check compressor pressure (ensure 8 bar max.); Clean air inlet; Add pneumatic tool oil; Inspect and replace damaged hose. |
| Air leaking from connections | Loose connections; Damaged O-rings/seals; Insufficient Teflon tape. | Tighten all connections; Replace worn seals; Reapply Teflon tape to threaded connections. |
| අධික කම්පනය | Worn internal components; Loose socket. | Contact authorized service center; Ensure socket is securely attached. |
පිරිවිතර
| විශේෂාංගය | පිරිවිතර |
|---|---|
| ආකෘතිය | TC-PW 610 (Part No. 4138965) |
| උපරිම. මෙහෙයුම් පීඩනය | 8 බාර් |
| උපරිම. ව්යවර්ථය | 610 Nm |
| Drive Square | අඟල් 1/2 |
| භ්රමණ සැකසුම් | 1-level left rotation, 3-level right rotation |
| Recommended Hose Inner Diameter | අවම 9 මි.මී |
| අයිතමයේ බර | 1.14 kg (රාත්තල් 2.51) |
| නිෂ්පාදන මානයන් | අඟල් 7.28 x 4.72 x 2.56 |
| ඇතුළත් සොකට් | 17mm, 19mm, 21mm |
Figure 10: Key specifications: 8 bar max pressure, 610 Nm high power, and 1/2 inch drive.
වගකීම් සහ සහාය
Einhell products are manufactured to high-quality standards and undergo strict quality controls. This product is covered by a manufacturer's warranty. Please refer to the warranty card included with your product for specific terms and conditions, including warranty period and claim procedures.
For technical support, spare parts, or service inquiries, please contact Einhell customer service. Contact information can typically be found on the Einhell official webඅඩවිය හෝ නිෂ්පාදන ඇසුරුම්කරණය මත.
අයින්හෙල් නිල Webඅඩවිය: www.einhell.com
