Pard USA Night Stalker Mini Digital Night Vision Scope Instruction Manual

1. හැඳින්වීම

The Pard USA Night Stalker Mini Digital Night Vision Scope is an advanced optical device designed for enhanced visibility in low-light and nighttime conditions. Featuring a 35mm objective lens, 3x optical magnification, and 2x digital zoom, it provides clear imaging through its 2560x1440 CMOS sensor with 0.001 lux sensitivity. The device includes a 800x800 circular IPS display with 100mm eye relief for comfortable viewing and offers various advanced features for optimal performance.

2. පෙට්ටියේ ඇති දේ

Upon unboxing your Night Stalker Mini, verify that all components are present:

• Pard Night Stalker Mini Digital Night Vision Scope
• පිකාටින්නි ​​රේල් කන්ද
• USB-C කේබලය
• Two 18650 Flat Top Rechargeable Batteries (3200mAh)
• Torx Key and additional screws
• රෙදි පිරිසිදු කිරීම
• User Manual (brief literature)

3. පිහිටුවීම

3.1 බැටරි ස්ථාපනය

To install the 18650 battery:

1. Unscrew the battery cover located at the rear of the unit.
2. Insert the 18650 battery with the positive (+) end first.
3. Securely screw the battery cover back into place.

Note: The threads for the battery compartment are precisely cut, ensuring a smooth fit. However, the compartment is not O-ring sealed, so exercise caution in wet conditions.

3.2 Mounting to a Picatinny Rail

The Night Stalker Mini is designed for Picatinny rail mounting and includes the necessary adapter.

1. Install the included mount to the bottom of the Night Vision optic using the provided screws.
2. Place the unit onto your firearm's Picatinny rail.
3. Tighten the mount to 25 lb/in for secure attachment.

රූප විස්තරය: A man aiming a rifle equipped with the Pard Night Stalker Mini digital night vision scope. The scope is mounted on a Picatinny rail, demonstrating its intended use as a weapon-mounted optic. The image highlights the compact and ergonomic design of the scope in a field setting.

3.3 Getting a Sharp Image

To achieve the sharpest possible image:

1. සකස් කරන්න නාභිගත වළල්ල (located in the middle of the unit) to bring the target into clear view.
2. සකස් කරන්න diopter adjustment handwheel (at the eyepiece) to fine-tune the image clarity for your individual eyesight.
3. Once adjusted, tighten the අගුලු දැමීමේ වළල්ල on the diopter to secure the setting.

රූප විස්තරය: A detailed diagram of the Pard Night Stalker Mini digital night vision scope, highlighting its key components. Labels point to the 35mm objective lens, quick function buttons, menu/adjustment dial, lithium-ion 18650 battery compartments, power button, innovative side focus, and the optional IR light module. This image serves as a visual guide for identifying the various parts of the device.

4. මෙහෙයුම් උපදෙස්

4.1 පාලනය අවසන්view

The Night Stalker Mini features an intuitive control panel for easy operation:

• බල බොත්තම: Press and hold for 1.5 seconds to turn the unit on/off.
• Menu/Adjustment Dial: සැකසුම් ගැලපීම් සඳහා ප්‍රධාන මෙනුවට ප්‍රවේශ වේ.
• ඉක්මන් ක්‍රියාකාරී බොත්තම්: Provides quick access to frequently used features.
• IR Illuminator Button: Toggles the infrared illuminator on/off and adjusts brightness levels (short press for on/off, long press to cycle brightness).
• Video Recording Button: වීඩියෝ පටිගත කිරීම ආරම්භ කර නතර කරයි.
• Still Shot Button: Captures a single image.
• හරි/ඇතුළු කරන්න බොත්තම: මෙනුව තුළ තේරීම් තහවුරු කරයි.
• ඉහළ/පහළ/වම්/දකුණු ඊතල: Navigates menu options and adjusts settings.

4.2 IR Illuminator

The integrated 5-watt IR illuminator provides visibility up to 300 meters. Use the dedicated IR button to activate and adjust its intensity. For optimal performance in extreme darkness or at longer ranges, an auxiliary IR illuminator (such as the TL3U IR light module, sold separately) can be added.

4.3 Digital Magnification

The device offers 2x digital magnification in addition to its 3x optical magnification. Use the Up/Down arrow buttons to adjust the digital zoom level. Be aware that increasing digital magnification may reduce image crispness.

4.4 රෙටිකල් ගැලපීම

The Night Stalker Mini supports multiple reticle styles and colors. To change the reticle:

1. ඔබන්න Crosshair button to activate the reticle display.
2. Use the Up/Down arrows to cycle through the available reticle designs.
3. ඔබන්න හරි බොත්තම ඔබගේ තේරීම තහවුරු කිරීමට.

රූප විස්තරය: A visual representation of the various display options available on the Night Stalker Mini. It illustrates six different reticle styles, four image modes (including color and mono), four reticle colors, and three scene modes, providing users with customization for different viewකොන්දේසි.

4.5 Zeroing the Optic

To zero your Night Stalker Mini:

1. Mount the optic securely on your firearm.
2. Take a shot at your desired zeroing distance (100 yards recommended).
3. Identify the bullet impact point on the target.
4. ඔබා අල්ලාගෙන සිටින්න හරි බොත්තම until the reticle on the display turns black.
5. Using the Up/Down/Left/Right arrow buttons, move the reticle to align with your bullet's impact point.
6. Once the reticle is aligned, press the හරි බොත්තම again to save the zeroing settings. The unit is now zeroed.

4.6 පටිගත කිරීම සහ නැවත ධාවනය

The Night Stalker Mini supports video recording and still image capture to a 32GB Micro SD card (included). The unit also features recoil-activated recording.

• පටිගත කිරීමට: ඔබන්න වීඩියෝ පටිගත කිරීමේ බොත්තම පටිගත කිරීම ආරම්භ කිරීමට සහ නැවැත්වීමට.
• To Capture a Still Image: ඔබන්න Still Shot button.
• නැවත ධාවනය කිරීමට: ඔබා අල්ලාගෙන සිටින්න Menu/Play button to access stored files. Use the arrow buttons to navigate and the OK button to play/view.
• දත්ත හුවමාරුව: Files can be transferred by connecting the unit to a computer via the USB-C cable or by removing the Micro SD card and inserting it into a card reader.

5. නඩත්තු කිරීම

Proper maintenance ensures the longevity and optimal performance of your Night Stalker Mini.

• පිරිසිදු කිරීම: Use the provided cleaning cloth to gently wipe lenses and the display. For stubborn smudges, use a lens cleaning solution specifically designed for optics. Avoid abrasive materials.
• ගබඩා: Store the unit in a dry, cool place away from direct sunlight. Ensure the objective lens cap is in place to protect the lens from dust and scratches.
• බැටරි සත්කාර: Remove batteries if the unit will not be used for an extended period. Store batteries in a cool, dry place.

6. දෝශ නිරාකරණය

If you encounter issues with your Night Stalker Mini, refer to the following common solutions:

• බලය නැත: Ensure batteries are correctly installed and fully charged. Check the battery compartment for any debris.
• අපැහැදිලි රූපය: Adjust the focus ring and diopter for optimal clarity. Ensure lenses are clean.
• IR Illuminator Not Working: Check if the IR illuminator is turned on via its dedicated button. Ensure the unit is in night mode if applicable.
• පටිගත කිරීමේ ගැටළු: Verify that the Micro SD card is properly inserted and has sufficient storage space. The card may need to be formatted.
• සම්බන්ධතා ගැටළු: If using Wi-Fi, ensure the device is within range of your smartphone and the PardVision2 app is updated.

For further assistance, contact Pard USA customer support.

7. පිරිවිතර

8. වගකීම් සහ සහාය

The Pard USA Night Stalker Mini Digital Night Vision Scope comes with a warranty. Please refer to the "Warranty Description: Amazon" in the product specifications for details on coverage. For technical support, service, or warranty claims, please contact the manufacturer, Pard, or refer to the official Pard USA webසම්බන්ධතා තොරතුරු සඳහා අඩවිය.

නිෂ්පාදකයා: Pard
